High gain for excellent point to point
Narrow beamwidth and High F/B ratio minimize other system interferencFrequency: 1710-2700MHz, Gain: 14dBi, Beamwidth: 32deg, Pol: V or H, Size: 520x110mm
Marks: The radome protects the antenna against snow, ice and other adverse environmental conditions which can degrade performance and cause damage.
Frequency: 1920-2170MHz, Gain: 14dBi, Beamwidth: 32deg, Pol: V or H, Size: 650x42x95mm
Marks: High gain yagi antennas which provide excellent point to point communications in RF control, short or long back haul link, point to multipoint.
Frequency: 1920-2170MHz, Gain: 14dBi, Beamwidth: 32deg, Pol: V or H, Size: 540x110 mm
Marks: The radome protects the antenna against snow, ice and other adverse environmental conditions which can degrade performance and cause damage.
Frequency: 1850-1990 MHz, Gain: 14dBi, Beamwidth: 30deg, Pol: V or H, Size: 560x110 mm
Marks: The radome protects the antenna against snow, ice and other adverse environmental conditions which can degrade performance and cause damage.
Frequency: 824-895 MHz, Gain: 15dBi, Beamwidth: 30deg, Pol: V or H, Size: 1000 x 200x 60mm
Marks: High gain for excellent point to point, Full folded dipole construction, Narrow beamwidth minimise other system interference. Available in welded construction
Frequency: 698-806 MHz, Gain: 11dBi, Beamwidth: 35deg, Pol: Vertical, Size: 1010 x 225 x 60mm
Marks: High gain yagi antennas which provide excellent point to point communications in RF control, short or long back haul link, point to multipoint.
Frequency: 806-960 MHz, Gain: 11dBi, Beamwidth: 30deg, Pol: Vertical, Size: 1100 x 210 x 85mm
Marks: High gain for excellent point to point, Full folded dipole construction, Narrow beamwidth minimise other system interference. Available in welded construction
Frequency: 806-960 MHz, Gain: 11dBi, Beamwidth: 45deg, Pol: Vertical, Size: 910 x 190 x 80mm
Marks: High gain yagi antennas which provide excellent point to point communications in RF control, short or long back haul link, point to multipoint.
