2.4GHz 9dBi 180deg MiMO Sector Antenna
Model : DS2400G9180D

Frequency:2400-2500MHz, Gain: 2x9dBi, Beamwidth: 180deg, Pol: Vertical & Horizontal, Size: 210x160x80mm

Marks: It is suitable for indoor or outdoor use, and feature high-gain directional transmission and represent an excellent solution for providing wide coverage, ideal for Point to Multi-Point connections.

PDF Download
2.4GHz 16dBi 120deg MiMO/Dual Polarized Sector Antenna
Model : DS2400G16120D

Frequency:2400-2500MHz, Gain: 2x16dBi, Beamwidth: 90deg, Pol: Vertical & Horizontal, Size: 1150x160x80mm

Marks: It is suitable for outdoor use, and feature high-gain directional transmission and represent an excellent solution for providing wide Coverage, for the applications: s IEEE 802.11b, 802.11g and 802.11n wireless LAN systems.

PDF Download
2.4GHz 16dBi 90deg MiMO/Dual Polarized Sector Antenna
Model : DS2400G1690D

Frequency:2400-2500MHz, Gain: 2x16dBi, Beamwidth: 90deg, Pol: Vertical & Horizontal, Size: 800x160x80mm

Marks: Dual Polarized Sector Antenna combines high gain with 90 deg beamwidth, ideal for the wifi mimo wireless internet cell site, for the applications includes IEEE 802.11b, 802.11g and 802.11n wireless LAN systems.

PDF Download
2.4GHz 14dBi MiMO Sector Antenna
Model : DS2400G14120D

Frequency:2400-2500MHz, Gain: 2x14dBi, Beamwidth: 120deg, Pol: Vertical & Horizontal, Size: 500x160x80mm

Marks: It is suitable for outdoor use, and feature high-gain directional transmission and represent an excellent solution for providing wide coverage, ideal for Point to Multi-Point connections. IEEE 802.11b, 802.11g &IEEE 802.11n Wireless LAN

PDF Download
High Gian MiMO Sector Antenna
Model : DS2400G18120D

Frequency:2400-2500MHz, Gain: 2x18.3dBi, Beamwidth: 120deg, Pol: Vertical & Horizontal, Size: 1600x160x80mm

Marks: It is suitable for outdoor use, and feature high-gain directional transmission and represent an excellent solution for providing wide coverage, ideal for Point to Multi-Point connections.

PDF Download
High Gian Dual Polarized Sector Antenna
Model : DS2400G2090D

Frequency:2400-2500MHz, Gain: 2x20dBi, Beamwidth: 90deg, Pol: Vertical & Horizontal, Size: 1600x160x80mm

Marks: It is suitable for outdoor use, and feature high-gain directional transmission and represent an excellent solution for providing wide coverage, ideal for Point to Multi-Point connections.

PDF Download
2.4GHz 17dBi 65 Dual Polarized Sector Antenna
Model : DS2400G1765D

Frequency:2400-2500MHz, Gain: 2x17dBi, Beamwidth: 65deg, Pol: Vertical & Horizontal, Size: 700x160x80mm

Marks: Dual Polarized Sector Antenna combines high gain with 90 deg beamwidth, ideal for the wifi mimo wireless internet cell site, for the applications includes IEEE 802.11b, 802.11g and 802.11n wireless LAN systems

PDF Download
2.4GHz 15dBi MiMO Sector Antenna
Model : DS2400G1565D

Frequency:2400-2500MHz, Gain: 2x15dBi, Beamwidth: 65deg, Pol: Vertical & Horizontal, Size: 455x160x80mm

Marks: It is suitable for outdoor use, and feature high-gain directional transmission and represent an excellent solution for providing wide coverage, ideal for Point to Multi-Point connections.

PDF Download
5GHz 14dBi 120deg Sector Antenna
Model : DS5000G14120

Frequency:5100-58500MHz, Gain: 14dBi, Beamwidth: 120deg, Pol: Vertical, Size: 450x114x55mm

Marks: Improves RF Performance & Versatility in High-Capacity, Point-toMultipoint Deployments. Create A Powerful Wireless Base Station with Coverage up to 1.86 Miles/3km.

PDF Download
5GHz 16dBi 120deg Sector Antenna
Model : DS5000G16120

Frequency:5100-58500MHz, Gain: 16dBi, Beamwidth: 120deg, Pol: Vertical, Size: 750x114x55mm

Marks: Sector Antennas are designed to improve RF performance and versatility in high-capacity, long-range, point-tomultipoint deployments. Join the Sector Antenna with an outdoor access point to create a powerful, environmentally resistant.

PDF Download
2.4GHz 14-18dBi 90-35deg Sector Antenna
Model : DS2400G1418A

Frequency:2400-2500MHz, Gain: 14-18dBi,  Beamwidth: 90-35deg, Pol: Vertical, Size: 600x320x140mm

Marks: This sector antenna with two AL reflectors, make horizontal beamwidth and gain adjustable for flexible wifi hotspot environment required. The max H-plane beamwidth up to 90deg , with the gain 14dBi. Narrow the reflecting wing will offer considerable gain up to 18dBi.

PDF Download
2.4GHz 18dBi 90deg Sector Antenna
Model : DS2400G1890

Frequency:2400-2500MHz, Gain: 18dBi, Beamwidth: 90deg, Pol: Vertical or Horizontal, Size: 1000x180x90mm

Marks: This high gain Sector Antenna is designed for use in outdoor point to multipoint environments. four-Antenna Array for 360° coverage, 2.4GHz ISM band: IEE802.11b and 802.11g, bluetooth, and public wireless hotspots.

PDF Download
2.4GHz 16dBi 65deg Sector Antenna
Model : DS2400G1665

Frequency:2400-2500MHz, Gain: 16dBi, Beamwidth: 65deg, Pol: Vertical or Horizontal, Size: 800x180x90mm

Marks: This Sector Antenna is designed for use in outdoor point to multipoint environments. Six-Antenna Array for 360° coverage, 2.4GHz ISM band: IEE802.11b and 802.11g, bluetooth, and public wireless hotspots.

PDF Download
